TP4056 1A Li-ion 18650 Battery Charging Board with Protection (Type-C USB)
Complete constant-current/constant-voltage linear charger for single cell 3.7V lithium-ion/18650 batteries with built-in DW01A over-discharge protection.
TP4056 1A Li-ion 18650 Battery Charging Board with Protection (Type-C USB) is an authentic, engineering-grade hardware component designed for prototyping, robotics, and academic research. Includes verified schematics, pre-tested hardware, and nationwide express shipping across Pakistan.
The TP4056 Type-C Lithium Battery Charger Module is the must-have charging and battery management board for all portable electronics projects.
Key Engineering Features:
- Modern Type-C USB Interface: Plug directly into your phone charger or laptop USB port.
- Complete Dual Protection Circuit: Features the DW01A protection IC and FS8205A dual MOSFETs to protect batteries against over-charging, over-discharging (below 2.5V), and short circuits.
- Dual Status Indicator LEDs: Red LED indicates charging in progress; Blue/Green LED indicates charge complete.
- CC/CV Charging Profile: Safe constant-current / constant-voltage charging algorithm prolongs 18650 cell life.
Common Engineering Applications:
- DIY power banks and portable handheld IoT devices
- Rechargeable battery packs for robot cars and ESP32 projects
- Solar battery backup charging stations
- Safe 18650, LiPo, and 14500 single-cell lithium charging
What's Included in the Package:
- 1x TP4056 Type-C USB 18650 Lithium Battery Charger Board with Battery Protection IC
Quick Build & Interfacing Guide:
Unbox and verify all pre-tested sensors, microcontrollers, and wiring components included in your package.
Secure mechanical brackets, servos, and modules to the main frame using the provided mounting hardware.
Interface VCC, GND, and GPIO signal lines according to the verified schematic diagram provided with the kit.
Upload the tested source code via Arduino IDE, Python, or ESP-IDF and verify live sensor readings and actuation.
Need a Custom 3D Printed Casing or Multilayer PCB?
Get custom snap-fit enclosures and robotics parts printed via our custom 3D printing service in Lahore & Pakistan, or order industrial double-sided circuit boards through our custom PCB fabrication service with nationwide delivery.
