TCS3200 Color Sensor Recognition Detector Module
Programmable color light-to-frequency converter module with 4 bright white LEDs for color sorting robots, textile analysis, and machine vision.
TCS3200 Color Sensor Recognition Detector Module is an authentic, engineering-grade hardware component designed for prototyping, robotics, and academic research. Includes verified schematics, pre-tested hardware, and nationwide express shipping across Pakistan.
The TCS3200 Color Sensor Module brings digital color recognition to robotics, sorting conveyors, and automated quality-control projects.
Key Engineering Features:
- 8x8 Photodiode Matrix: 16 photodiodes with red filters, 16 with green filters, 16 with blue filters, and 16 clear photodiodes.
- Light-to-Frequency Conversion: Converts light intensity into a clean square wave whose frequency is directly proportional to color brightness.
- 4 Integrated White LEDs: Built-in object illumination LEDs ensure consistent color readings regardless of external room lighting.
- Direct Microcontroller Interface: Connects directly to any digital timer/counter pin on Arduino, ESP32, or PIC.
Common Engineering Applications:
- Automated candy, pill, or component color sorting robotic arms
- Textile and fabric color shade matching
- Line following robots with color-coded stop and turn commands
- Liquid color analysis in automated chemistry test benches
What's Included in the Package:
- 1x TCS3200 Color Recognition Sensor Module with Removable Optical Lens Housing
Quick Build & Interfacing Guide:
Unbox and verify all pre-tested sensors, microcontrollers, and wiring components included in your package.
Secure mechanical brackets, servos, and modules to the main frame using the provided mounting hardware.
Interface VCC, GND, and GPIO signal lines according to the verified schematic diagram provided with the kit.
Upload the tested source code via Arduino IDE, Python, or ESP-IDF and verify live sensor readings and actuation.
Need a Custom 3D Printed Casing or Multilayer PCB?
Get custom snap-fit enclosures and robotics parts printed via our custom 3D printing service in Lahore & Pakistan, or order industrial double-sided circuit boards through our custom PCB fabrication service with nationwide delivery.
