L298N Dual H-Bridge DC & Stepper Motor Driver Controller Board
High-power dual H-bridge motor driver board capable of driving two DC motors or one 4-wire bipolar stepper motor with speed and direction control.
L298N Dual H-Bridge DC & Stepper Motor Driver Controller Board is an authentic, engineering-grade hardware component designed for prototyping, robotics, and academic research. Includes verified schematics, pre-tested hardware, and nationwide express shipping across Pakistan.
The L298N Dual H-Bridge Motor Driver is the most widely trusted motor controller module for robotics, RC vehicles, and smart automation projects in Pakistan.
Key Engineering Features:
- Dual Full-Bridge Drive: Controls speed (PWM) and rotation direction of 2 independent DC motors or 1 2-phase 4-wire bipolar stepper motor.
- Heavy-Duty Aluminum Heat Sink: Dissipates heat during continuous heavy motor loads.
- Onboard 5V Linear Regulator (78M05): Powers external microcontrollers or logic directly from the motor battery pack (up to 12V drive).
- Screw Terminal Blocks: Solid, vibration-proof terminal connections for high-current motor power wires.
Common Engineering Applications:
- 2WD and 4WD obstacle avoiding robot cars
- Line follower robotics and AGVs (Automated Guided Vehicles)
- CNC slide tables and stepper motor positioners
- Dual DC motor speed and forward/reverse direction controllers
What's Included in the Package:
- 1x L298N Dual H-Bridge Motor Driver Board with Pre-Mounted Aluminum Heat Sink
Quick Build & Interfacing Guide:
Unbox and verify all pre-tested sensors, microcontrollers, and wiring components included in your package.
Secure mechanical brackets, servos, and modules to the main frame using the provided mounting hardware.
Interface VCC, GND, and GPIO signal lines according to the verified schematic diagram provided with the kit.
Upload the tested source code via Arduino IDE, Python, or ESP-IDF and verify live sensor readings and actuation.
